What are plans and elevations?
Plans and elevations are a way of representing a 3-dimensional object. We have three views of the 3D shape. In this unit learners will learn about plans and elevations, including what they are, how to construct them and how to interpret plans and elevations to generate a 3D image. See Preview Here.
They will learn the three views of a 3D shape:
- From the front of the shape, called the front elevation
- From the side of the shape, called side elevation
- From above looking down on the shape, called the plan view
This amazing interactive resource bundle also includes plans and elevations worksheets based on Edexcel, AQA and OCR exam questions with answers for that extra work.
