Learning to draw in orthographic 3rd angle projection

This is a clear and user friendly visual step-by-step teaching resource to teach KS3/KS4 how to draw a catapult in 3rd angle projection using Powerpoint. It includes a plan, front elevation and side elevation with sizes that will fit onto A4 sized paper.

This resource is ideal to set students up ready for GCSE resistant materials or graphic design, which requires students to draw a plan of their project using orthographic projection before making it,

This resource differentiates through provision of a sound understanding for lower ability students and also extension tasks for those students who are high ability.
